Garage Door Photo Gallery

Use this garage door photo gallery to put names to the parts we talk about on our service pages. The pictures show typical garage door work, not specific Newport jobs.

What the Garage Door Photo Gallery Shows

Springs on the bar above the door, cables at the bottom corners, rollers in the tracks and openers on the ceiling. Tap a photo to see it larger.

Close to the harbor, these are also the parts where salt air shows first: orange spots on spring coils, loose strands at the cable ends and rollers that turn rough. Use the captions to put a name on what you see in your own garage, then tell us which photo looks closest when you call.

Interior face of a white sectional door with reinforcement struts — The inside of a white sectional door, where steel struts run across each section to keep it from bowing.

Technician on a stepladder beside a garage door with steel shafts on the floor — A stepladder at the header of the door, with the bare steel spring shafts laid out on the floor below.

Technician kneeling on a garage floor assembling a torsion spring shaft on a drop cloth — A torsion shaft being assembled on a drop cloth, so the springs and drums are set before it goes up.

Close view of a technician working on a garage door track and panel — Up close at the door edge, where a roller bracket meets the track and the section beside it.

Partly open garage door above a silver car, with two ladders in the work area — A door stopped partway up over a parked car, with a ladder on each side of the opening.

A person in a black shirt reaching up beside a curved door track — The curved piece of track, where the door turns from the wall onto the ceiling rails.

A person on a ladder holding a cordless drill beside a torsion spring — A cordless drill in hand next to a torsion spring that sits on its bar above the opening.

Two technicians beside a dark sectional door at a residential garage — Two technicians outside a home garage beside a dark sectional door.

Two technicians on ladders adjusting the tracks of a garage door — Ladders on both sides so each track can be set to the same height and distance from the door.

Two technicians lifting a curved door track into place, with new door sections on the floor — Two technicians lift a curved track into place while new door sections lie flat on the floor.

Technician on a stepladder at the top of a paneled garage door — Work at the top section of a paneled door, the part that carries the opener bracket.

A person adjusting a raised garage door from inside with a car outside — A raised door checked from inside the garage, with a car parked out on the driveway.

Match a Photo to a Service

The shots of spring shafts and the drill beside a coil go with spring repair. The track close-ups and the curved rail line up with track repair. A door that hangs low on one corner usually points to cable repair. The strut and top-section views relate to panel replacement. The photo with new sections on the floor shows a full new door installation. See the pricing page for spring, cable and track starting prices.

Spotted a part on your own door that looks like trouble? See our services or call (949) 763-3239.
